Channels: 6
Spread Spectrum: FHSS
Antenna Length: 106mm
Model: Cars/Boats/Glider/Fixed-wing aircraft etc.
Operating Current: 80mAh-120mAh
Frequency: 2.4GHz ISM band (2400MHz-2483.5MHz)
Control Distance: over 600 meters on land - over 1000 meter on water
Operating Voltage: 4.8-15.0V DC(2s-4s lipo battery or 6*1.5AA)
Screen: 128*64 resolution, LCD back light
Low Voltage Alert: Yes(Below 4.6V)
Size: 22.4*17.5*11.6cm
Weight: 323g
R7FG Receiver Specifications:
Channels: 7ch
Signal output: PPM/PWM/S-BUS, 2.4GHz
Receiver operating voltage: 4-10V
Modulation Mode: GFSK
Antenna Length: 200mm
Control Distance: over 600 meters on land over 1000 meter on water
RF Power: <10dbm
Channel resolution: 4096
Working Current: 30mA
Applicable model: car, boat
Size: 3.5*1.8*1.5cm
Weight: 6g
Link til produsent KLIKK HER - mye mer info her.
Brukermanual KLIKK HER
Setting simplicity, fast response for 6 channels, Model's voltage Real-time Telemetry, Cruise Control, Dual Mix Steering Control, USB upgrade firmware,Throttle Lock, Voltage Protection,ABS and fail-safe protection, Subsidiary ID, outstanding range up to 600 meters and more features. (actual control distance is according the local environment). We add strap hook, hole for FPV monitor, improve the handle shape, change the switches position to enhance using experience. RC6GS V2 RC Remote Control Transmitter
Features:
1.【Excellent Anti-interference】: Real pseudo random algorithm FHSS communication technology makes RC6GS V2 control distance up to 1900 feet (600meters), and over 20 units of RC6GS V2 can work simultaneously at one place without any interference.
2.【Built in Gyro】: R7FG built-in gyro can keep the vehicle in a straight line, and Gyro sensitivity can be adjusted by transmitter, which fits for drifting and on-road cars.
3.【Two-way Transmission Return】: Real-time signal strength, RX battery voltage EXT (Model battery voltage) can be dispaly on the RC6GS V2 screen. (Only support works with R7FG or R8F)
4. 【Customized Channels】: CH3-CH6 can be customized to VR, three-way switch and tact switch, the tact switch can be used for cruise control mode, a good idea for crawler, all channels' fail-safe values can be set to any value as you need.
5. 【Dual Programmable Mix Control】: Mix control can be programmed with any two channels and each channel can be customized. That's friendly for twin-engine vehicles, such as tanks, boats, 4 wheel steering car.
6. 【Adapts to Most of Types Vehicles】: with 10 models storage and each model can be set up and named separately. It is suitable for RC rock crawler, monster truck, Baja, off-road RC car, etc.
7. 【Superb Ergonomics】: The handle shape is more linear and handy with the ergonomic design. The strips on the trigger increase the touching friction. Added Hook, FPV monitor holder hole, middle of the handle SWD switch, user can personalize by changing SWA to SWD.
8.【Low Power Consumption】: anti-polarity connect protection technology to keep your transmitter safety, JST connector supports multiple batteries: liPo or 6*AA.(NOT INCLUDED)
Package Included:
Radiolink RC6GS V2 transmitter x 1
Radiolink R7FG Receiver x 1
User Manual x 1
Neck Strap x 1
Telemetry Cable x 1
