5,8 Ghz 40 kanaler mikro FPV kamera 25 mW

Sensor	1/4 " CMOS
Bilde	16:9
Power	3,6 - 5,5 volt 380 mAh
Oppløsning	480 x 320
TV System	NTSC / PAL (switchable)
Brightness	350 cd/m2
Størrelse	18 x 16 x 16 mm
Vekt	3,9 gram

FPV Camera

Sensor: 1/4 "CMOS
Lens: M8 800TVL Lens
Angle: 150 ° FOV horizontal viewing angle of 170 ° DFOV diagonal perspective
Format: NTSC / PAL (switchable)
Power consumption: 380mA @ 3 · 7V
Power: 3.6-5.5V
Lens Mirror Diameter: 2.1mm IR coated FOV150 (horizontal)

Video Transmitter

Support video format: NTSC / PAL
Output Impedance: 75 Ohm
Output signal strength: 23 ~ 24dBm
Output Power: 25mW
Wireless Channel: 40CH
Antenna: RHCP circular polarization clover leaf antenna
Operating voltage: 3.6V ~ 5.5V
Current: 100mA
Audio carrier: 6.5MHz

Button function
Short press (Apr. 1 sec or less): Change channels 1-8
Long press (More than 1.5 sec): Change bands A-B-E-F-R
Long + press (More than 3 sec): Change NTSC/PAL system
NTSC or PAL (selectable; Blue LED on= NTSC; Blue LED off=PAL)

Body

Weight: 3.6g
Size: 18x16x16mm (without antenna)

Feature:

AIO FPV camera, transmitter , antenna all 3 functions in one limit size and weight
150 ° FOV horizontal viewing angle of 170 ° DFOV diagonal perspective
Five bands 40 channels with Race band

New design. Upgraded Open Source Receiver, increases the sensitivity of receiver
Auto search, you can search all frequencies around or select your own frequency to avoid interference
Add the power indicator function instead of the built-in buzzer, you can check the power on displayer directly.
With white noise and snow screen
Dual receiver to get strong and steady signal
Support Lens Adjustable
Support upgrading
With comfortable face sponge
